Description
Bluetooth 5.0 + EDR : Max speed up to 3Mbps Single-chip Bluetooth 5 controller, combines a BT Protocol Stack (LM, LL, L2CAP, GATT, RFCOMM, SPP, and LE), BT Baseband, modem, and BT RF in a single chip Supports dual mode (BR/EDR + LE Controllers), compatible with previous versions, including v2.1 + LE Supports Bluetooth Low Energy (BLE) - multiple Low Energy states Supports Bluetooth classic (BDR/EDR) Supports Windows 8.1/10, Linux: Kernel 2.6.32 - 5.3 or above (support Fedora & Ubuntu only) HARDWARE Interface •1 x USB 2.0 Type A Antenna •Internal PiFa Antennas x 1 Dimensions •7.1 (H) x 14.9 (W) x 17.4 (D) mm Weight •2g BLUETOOTH Standards •Bluetooth 5 specification compliant Frequency Band •2402~2480MHz Maximum Data Speed •3Mbps (class BT-BR/EDR) : 2Mbps(BLE) Output Power •8dB (max.) Receiver Sensitivity 94dBm (2Mbps EDR) 87dBm (3Mbps EDR) 98dBm (BLE) 06dBm (125K BLE long range) OTHERS Certification •CE, FCC, NCC, BSMI, BQB Environmental Condition •Operating Temperature: 32~104°F (0~40°C) •Storage Temperature: -4~140°F (-20~60°C) •Operating Humidity: 10~90% (NonCondensing) •Storage Humidity: Max. 95% (NonCondensing) System Requirement •Windows 8.1/10 32bit/64bit or above •Linux: Kernel 2.6.32 - 5.3 or above (support Fedora & Ubuntu only) Installation •Easy setup wizard with auto run configuration Package Content •Bluetooth 5.0 USB Adapter •Quick Installation Guide
