Description
Key Features:
Built-in protection: Over current protection, over voltage protection, short circuit protection
More than 87% conversion efficiency
Compatible with HP Notebook
Replace Adapter P/N :
DELL PA-10, PA-12, NADP - 90KB, PA-1900-02D, PA-1900-02D2
Specifications
AC Socket
IEC60320 C8(Small 2 pins) ADP193-31
Input voltage: 100-240VAC
Input frequency: 50/60Hz
Output Voltage: 18.05-19.95V
Output Current: 0-3.42A
Ripple/Noise≤250mV
Efficiency: ≥87% at full load
Hold up time: ≥5ms
Temperature range: Operating 0°C to 40°C
Output Watt: 65W
Dimension:108*46*30mm(L*W*H)
Compatibility:
Dell Inspiron 300M, 500M, 505M, 510M, 600M, 630M, 640M, 700M, 710M, M101z, M5010R, M102z, M501R
Dell Inspiron 1420, 1501, 1521, 1525, 1526, 1720, 1721,14V,15R, 14R,13Z,15Z
Dell Inspiron 6000, 6400, 8500, 8600, 9200, 9300, 9400
Dell Inspiron E1405, E1505, E1705
Dell Latitude D400, D410, D420, D430
Dell Latitude D500, D505, D510, D520, D530, D531
Dell Latitude D600, D610, D620, D630
Dell Latitude D800, D810, D820, D830
Dell Precision M20, M60, M70
Dell Vostro 1014, 1015, 1088, 3300, 3400
Package Content
1 x Notebook adaptor
