Description
OVERVIEW
The technologies applied and the components and materials used in the manufacturing of the FOCUS+ Platinum 750 watt power supply do not compromise on Seasonic’s legendary high standards. This product received 80 PLUS® Platinum certification, where efficiency reaches 92 % at 50 % system load. Superior dynamic response, great system stability, maximized 12 V DC rail output and a state-of-the-art fan control system are just some of the features that will awe enthusiasts who become familiar with this power supply. added: it is as good as irresistible.
SPECIFICATIONS
- 80PLUS®: Platinum
- Form Factor: Intel ATX 12 V
- Dimensions: 150 mm (W) x 140 mm (L) x 86 mm (H)
- Fan Information
- Fan Size: 120 mm
- Fan Control: Hybrid Silent fan Control
- Fan Bearing: Fluid Dynamic Bearing
- Life Expectancy: 70,000 hours at 40 °C, 15 % - 65 % RH
- Cable Information
- Modularity: Fully Modular
- Cable type: Flat black cables
- Electrical Features
- Operating Temperature: 0 - 50 °C
- MTBF @ 25 °C, excl. fan: 100,000 hours
- AC Input: Full Range
- Protection: OPP, OVP, UVP, OCP, OTP, SCP
- Safety and Environmental
- Safety and EMC: cULus, TUV, CB, CCC, BSMI, EAC, RCM
- Environmental Compliance: Energy Star, RoHS, WEEE, ErP Lot 6, REACH
