Camera Features
|
Camera system |
Dual camera system |
| Ultra wide camera |
Lens & Image sensor |
20MP Lens
SONY 1-inch CMOS |
| Maximum frame rate |
60fps |
| Field of view |
133° |
| PTZ camera |
Lens |
8MP lens |
| Maximum frame rate |
60fps |
| Zoom |
10x hybrid zoom (3.5x optical, 3x digital) |
| Field of view |
90° |
| AI features |
Auto faming & Speaker tracking |
| Conference security protection |
Electric camera lens cap, automatically protect non-video meeting |
|
Video Features
|
Video call quality |
up to 4Kp30 or 1080p60 |
| Bandwidth requirement |
4Kp30 from 2Mbps in H.265
1080p30 from 512Kbps in H.265
720p30 from 384Kbps in H.265 |
| Video packet Loss recovery |
30% |
| Local HD recording |
√ (USB flash drive, local storage or server recording) |
| Audio Device |
Microphone |
Built-in 8 MEMS microphone arrays |
| Optimal voice pickup distance |
20ft / 6 meters |
| Expansion Microphones |
Supports 2 x Wireless Expansion Mic
|
| Noise proof technology |
√ |
| Speaker |
Built-in speaker, 10W output |
| Controller |
Remote controller |
VCR20 Remote controller |
| Touch controller |
Supports CTP18 or CTP20 touch controller
|
| Collaboration Features |
Whiteboard |
√ |
| Annotation on content sharing |
√ |
| Multi-screen interaction |
√ |
| Reverse control |
√¡
|
|
Network & Security
|
Wi-Fi |
2.4G / 5G dual band |
| Bluetooth |
Bluetooth 4.2 |
| TCP/IP |
IPv4 & IPv6 |
| Communication protocols |
H.323 / SIP |
| Traversal features |
ICE/TURN/STUN/NAT/H.460 |
| Encryption |
SRTP/TLS/H.235/AES 256-bit |
Physical
Connections |
Display |
2 x HDMI output |
| Video input for content |
Supports WPP20/AirPlay/Miracast wireless content sharing¢
Supports VCH51 wired content sharing
|
| Line-in |
1 x 3.5mm Line-in |
| Line-out |
1 x 3.5mm Line-out |
| USB interface |
2 x USB 2.0 |
| Network interface |
1 x 10/100/1000Mbps Ethernet |
| Power adapter |
DC 48V/0.7A |
| Wall mounting kit |
√ |
| Video Codec |
H.265, H.264 High Profile, H.264, H.263, H.263+ |
| Audio Codec |
ARES, Opus, G.722.1C, G.722.1, G.722, G.711 (PCMU/PCMA), G.729 |
| Video Resolution |
4K, 1080P, 720P, 540P, 360P, 4CIF, CIF |
